LASER SCANNERS
FOR FURTHER INFORMATION ON THE FOLLOWING BRANDS PLEASE CALL JRC 1300 66 22 71
MS5145 Eclipse
Metrologic’s Eclipse is a single-line, hand-held laser scanner. Equipped with Metrologic’s patented CodeGate® technology, Eclipse can be used in a wide variety of applications. CodeGate® technology allows the user to easily target the desired bar code and complete the data transmission with a simple press of a button.
Overview
This makes Eclipse a perfect selection for menu scanning, point-of-sale, document processing and inventory control. With Metrologic’s state-of-the-art scanning
technology, the MS5145 Eclipse has a longer working range and a wider scan field than a typical CCD. The width of the scan line grows as the scanner moves further away from bar codes. CodeSense® is a unique feature employed by
Eclipse in the absence of Infrared object detection. It provides the user with a pulsing laser line for bar code detection. When a bar code is detected, the laser line switches to a constant state to allow for scanning via CodeGate®.
Quick Specs
Depth of Scan Field : 0 mm - 140 mm (0” - 5.5”) for 0.33 mm (13 mil) bar codes
Width of Scan Field : 49 mm (1.9”) @ face; 195 mm (7.7”) @ 140 mm (5.5”)
Scan Speed : 72 scan lines per second
Minimum Bar Width : 0.102 mm (4 mil)
System Interfaces : PC Keyboard Wedge, RS232, IBM 468x/469x, Stand Alone Keyboard, USB
Light Source : Visible Laser Diode 650 nm ± 10 nm
Features
CodeGate® : Ideal for menu scanning applications
CodeSense® : Automatically switches from “pulse mode” to continuous beaming when a bar code is detected
Powerlink cables : Uses the same user-replaceable cables and power supplies as Voyager®, Orbit® and Cubit®
Flash ROM : Update firmware from any PC via MetroSet2® software provided by Metrologic
OPOS and JPOS system compatible : Easily adaptable to any end-user system environment
Metrologic MS5145 Eclipse
