POLE DISPLAY
C-2202PD Pole Display
Features

  • Vacuum Fluorescent Display with display 20 columns and 2 lines
  • Blue-green fluorescent colour is easy on the eyes.
  • The display panel is movable so that it can be adjusted for the best viewing angle.
  • Adjustable height, short and long pole
  • Pass through function to reduce cable connections.
  • The self-test function checks the circuit board and performs each function for diagnostic purposes.
Part Number
Description
C2202PD
Ivory 2 line 20 character Pole Display, RS232 Interface
C2202PDBL
Black 2 line 20 character Pole Display, RS232 Interface
Specifications
C2202PD
Display Type
Blue Green Vacuum Fluorescent Display
Display pattern
5 x 7 Dot Matrix, Comma, Decimal Point
Brightness
700 cd/m²
Viewing Angle
+/- 30°
Horizontal rotating Angle
Max. 270°
Font Size
5.25(W) x 9.2(H) mm
Character pitch
8.3 mm
Character Number
20 Columns x 2 Lines
Character
PC-437/850/860/863/865, Slavonic, Russian, Katakana
Command
CBM Standard, ESC/POS
Interface
RS-232 interface
Pass Through Function
Pass-through function is standard
Operating Temperature
0 ~ 40 ºC
Operating Humidity
10 ~ 90%
Dimension (Panel)
(W x D x H)  230 x 42 x 100 mm
MTBF
25,000 hours
Weight
0.9 Kg
Safety
FCC class B, CE, C-tick
