LINEA PRO 6
The phenom. The latest sensation from Apple works wonders with our next-generation Linea Pro. For Apple iPhone 6.
FEATURES
  • Device Charging -
            5V through mini USB or station charger
  • Compatibility -
            iPhone 6
  • Power Consumption
            Deep sleep ~20uA
  • Magnetic Stripe Reader-
            3-track bidirectional reading capabilities
Type: ISO 7810, 7811, 7813
  • Barcode Scanner
            1D Laser or 2D high speed imager
Barcode Type    UCC/EAN 128, EAN 13, EAN 8, UPC A, UPC E, UPC E1, Code 11, Code 39, Code 93, Code 128, GS1, Matrix 2 to 5, Code 11, 2 of 5 industrial, 2 of 5 interleaved, Codebar, MSI/Plessey, UK/Plessey, IATA,ISBN, ISMN, ISSN, S-code, Telepen, RSS 14, RSS Limited, RSS-Expanded, PDF417, Data Matrix, QR code, Maxi code
  • RFID Reader
             - MIFARE MINI
- MIFARE CLASSIC-1K, MIFARE CLASSIC-4K
- MIFARE ULTRALIGHT, ULTRALIGHT-C
- ISO 14443, ISO 15693
- MIFARE PLUS 2K/4K
- DESFire card
  • LEDs
            4 LEDs for battery status
  • Buttons
            1 Scanning Button
  • Battery
            2040mAh battery
  • Cables
            Standard USB A to mini B cable
  • Audio Indicator
            Electromagnetic Buzzer
  • Environment
Operating Environment    - Operating temperature: 0C to +40C
- Operating humidity: 35 to 85% RH
- Storage temperature: -5C to +40C
- Storage humidity: 10 to 90% RH
  • Mechanical
Dimensions    - 1D scanner 157mm x 77mm x 22mm
- 2D scanner 157mm x 77mm x 27mm
Weight    147 grams
  • Software
Software Support    SDK for iOS platform
COMPATABILITY
Made for iPhone 6
