MS3780 Fusion
MS3780 Fusion
The Fusion 3780 combines omnidirectional and single-line laser bar code scanning into a lightweight and ergonomic hand-held form factor. The 20-line scan pattern provides superior scanning over existing single-line scanners, making Fusion ideal for medium-volume retailers including specialty stores, pharmacies, liquor stores, and convenience stores.
Quick Specs
  • Depth of Scan Field: (programmable) 25 mm - 279 mm (1 - 11) for 0.33 mm (13 mil) bar code at default setting

  • Width of Scan Field: 30 mm (1.2) @ 25 mm (1"); 150 mm (5.9) @ 280 mm (11)

  • Scan Speed: 1333 scan lines / sec, omnidirectional; 67 scan lines / sec, single line

  • Minimum Bar Width: 0.127 mm (5 mil)

  • System Interfaces: RS232, Keyboard Wedge, Stand Alone Keyboard, IBM 468x/469X, USB, OCIA

  • Light Source: Visible Laser Diode 650 nm

  • Standard MS3780 Colors : Light Grey or  Black

Fusion 3780 Scanner Features and Benefits

  • Primary omnidirectional scan pattern: Aggressive scanning of bar codes in any orientation, increasing throughput

  • Secondary single-line scan pattern: With a push of a button, switch to a targeted single-line for menu scanning

  • Automatic stand detection: Hands-free operation for presentation scanning, reducing operator fatigue
Copyright 2013 JRC International Pty Ltd. All Rights Reserved.

  • Sleep mode with IR wake up: Multiple sleep modes reduce power consumption, extending life and lowering cost of operation

  • Optional EAS integration: Deactivate an EAS tag and decode a bar code in a single scan
